Changyide electric mobile shelving with its higher scientific and technological content, humanized human-machine dialogue interface, good docking with the database, convenient control system upgrade, manual, electrical, computer control function integration, intelligent file query method and file storage location instructions, become a good helper of file management personnel.

Advantage of use

1. Complete computer communication function, not only through the computer to each partition, columns for flexible control (by clicking on the computer interface analog graphics can be manipulated at will, you can also double-click through the database file name directly open the corresponding dense shelf), and can be from the dense shelf to each partition, columns for operation.

2. Set manual, electrical, computer control function in one, function integration, but the three modes of operation are independent, do not affect each other, protect each other, prevent misaction.

1) The rack can be opened directly by clicking the simulated graphic or file name of the rack on the computer.

2) The key switch on the side of the rack can be opened directly by operating the rack.

3) The handle of the rack can be opened directly when the power is off.

4) By fixing the large LCD touch screen on the column, each column of dense shelves can be directly operated.

3. The database management interface is friendly and intuitive, built-in a variety of file information search methods, support fuzzy query. Make the query and retrieval of file data convenient and fast.

4. Provide several groups of general interface, convenient system function upgrade.

5. Intelligent ventilation management, click the "ventilation" button, dense frame and other gaps are distributed in each column position, to ensure that the file data is in a closed environment.

6. With infrared sensor, with infrared personal security protection function.

1) Infrared detection protection, the installation of infrared detection probes at the entrance of the dense shelf, when the file manager enters the dense shelf, it can automatically prohibit the movement of the dense shelf, and the text on the computer operating software prompts whether there are personnel in the dense shelf.

2) When the computer or After the key switch on the panel opens the dense frame, the dense frame electronic lock can automatically lock the dense frame, and the dense frame has been locked on the key panel and the computer operating software, in the case of unlocking the electronic lock, no operation can be carried out in this area of the dense frame, in order to protect the safety of the operator.

3) Brake safety protection, because in each column of the dense frame, all of them are equipped with a transmission mechanism, and all of them are equipped with a brake device to protect the movement of the dense frame. After the operator opens the dense frame, the brake switch can be turned off. No one can operate the dense frame in this area without opening the brake switch. When the dense frame is in operation, such as when the power is turned on or off, the operator is operating, etc., the voice prompt system will prompt according to the corresponding operation.

7. Lighting function (Note: When the dense frame is turned on, the lighting is automatically turned on, and when it is turned off, the lighting is automatically turned off.

8. Address positioning technology makes each column control circuit can be arbitrarily replaced to improve the reliability and maintainability of the product.

9. Visual dynamic display makes the execution of various operation commands at a glance.

5. Sizes

The following sizes are available for reference, and full-size customization is supported:

Features

1. With reliable center straightness, it is smooth and lightweight.

2. The steering wheel folding crank.

3. Load capacity: >600kg/m³.

4. Cabinet space utilization: >80%.

5. Transmission device: mechanism type automatic unhooking drive device. Sprocket production standards according to GB1135-89 and GB1244-84 standards, are processed by the mechanism, the surface after black rust treatment.

6. The transmission system adopts a special chain, double alignment adjustable roller bearings, rolling wheel using high-strength cast iron material, transmission mechanism rotation flexible, smooth, strong.

7. Each column cabinet structure is equipped with a brake device to ensure the personal safety of the personnel.

8. The use of a cold-rolled steel plate. There is a strong magnetic rubber sealing strip between the racks, a dustproof plate at the top and a rat-proof device at the bottom, which can meet the requirements of dustproof, rat-proof, anti-theft and anti-light.

Maintenance

1. The electric mobile shelving frame walking mechanism is chain drive, when the frame is used for a period of time, the bottom layer plate can be opened to fill the sprocket and bearing with lubricating oil.

2. The electric dense frame warehouse should be dry and ventilated.

3. The surface of the frame should not be exposed to sunlight for a long time.

4. Should keep the guide groove clean and free from dirt blockage.

5. The spray surface is strictly prohibited from scrubbing with gasoline, high alcohol, rosin water, banana water, which will make the spray surface tarnish and fade.

1. Material

The main body of electric mobile shelving system is made of double-layer cold-rolled steel plate structure, which is ISO9001 certified, and there is anti-rust and friction-resistant coating in the middle of the two layers of steel plate, which can resist the perforation damage caused by the electric drill on the outside. Antioxidant and electrostatic spraying are applied on the outside of the steel plate, polished and sprayed with anti-rust and ionization coating. The manual controller is made of ABS plastic, and you can choose its style and size independently.

2. Controller
Two modes of operation are available for opening the shelves, motorized push buttons and hand crank grips. Adopting automatic suspension gear, automatic homing, folding handle, easy to use. Beautiful appearance, comfortable hand feeling, its structure is ratchet automatic suspension, take off the gear, after deactivation can be parked in the vertical position, can avoid the channel obstacles, shaking any column will not drive the other handles.

3. Slides
The handle is equipped with 2 precision bearings, which are connected with the chain cycle to make the handle and the shaft flexible and lightweight, the slide rail under the shelf is made of galvanized solid square steel, and there are rubber seals inside the door plate to prevent the door plate and the frame from friction and collision. The chain is not easy to fall off during long-term use, and other parts are not easy to wear and prolong the life.

4. Driving system
The use of international advanced technology structure, gears for the 5-tooth drive, motorcycle chain for interlocking, the use of three component devices, dual-axis drive, central shaft drive, the frame at both ends at the same time the force is uniform, sturdy and durable, the frame has high strength, high carrying capacity, regardless of the frame combination of multiple widths, carrying multiples can ensure that the frame is balanced, parallel, lightweight and free to move forward, not easy to be damaged; not deformed for long-term use.



Multiple styles, multiple choices: bookcase mobile shelving, base map compact rack, manual rack for hanging clothes, documents, pictures, etc.
